Analysis of the Main Functions of the Constant Pressure Water Make-up System

As an important equipment widely used in industrial production and building water supply and drainage systems, the constant pressure water make-up system has its main function to maintain the stability of the liquid level in the system, ensure the normal operation of the system and improve the overall operating efficiency. The following are the main functions and detailed analysis of the constant pressure water supply ststem:

1. Maintain Constant System Pressure

One of the core functions of the constant pressure water supply system is to maintain constant system pressure. It monitors pressure changes in the system in real time through the built-in pressure sensor and automatically adjusts according to the preset pressure value. When the system pressure is lower than the set value, the device will automatically start the water make up function and inject an appropriate amount of water or other fluid media into the system through the water pump until the system pressure returns to the set range. This process ensures that the system maintains stable pressure under any working conditions, thereby avoiding damage to system equipment caused by pressure fluctuations.

2. Automatic Water Make Up and Leak Detection Function

The constant pressure water make-up system has the ability to automatically replenish water, and can promptly detect and replenish water lost in the system due to evaporation, leakage, etc. This function is achieved by monitoring the system liquid level or pressure in real time. Once the liquid level or pressure is found to be lower than the set value, the device will automatically start the water make upprocess to ensure that the system is always full of water. At the same time, the device also has a leak detection function. When a leak occurs in the system, it can respond quickly and take measures, such as closing the water make up valve, to prevent the leak from further expanding and ensure the safety of the system.

3. Save Energy, Reduce Consumption and Improve Efficiency

By accurately controlling the water supply volume and system pressure, the constant pressure water supply system can effectively reduce energy consumption and operating costs while achieving stable water supply. Traditional water replenishment methods often have the problem of excessive water replenishment or untimely replenishment, resulting in energy waste and low system efficiency. The constant pressure water make-up system adopts intelligent control technology, which can accurately replenish water according to the actual needs of the system, avoiding unnecessary energy consumption. In addition, by reducing the wear and failure rate of system equipment caused by pressure fluctuations, the constant pressure water supply system can further extend the service life of the system and improve the overall operating efficiency.

4. Exhaust and Degassing Functions

In some special application scenarios, such as air conditioning water systems, heating systems, etc., a large amount of gases and dissolved gases may accumulate in the system. The presence of these gases will not only affect the normal operation of the system, but may also cause damage to system equipment. The constant pressure water supply system can effectively discharge the gas in the system through the built-in exhaust valve and vacuum degassing device to ensure the normal operation of the system. At the same time, the vacuum degassing device can also remove dissolved gases and free gases in the water during the water replenishment process, improving water quality and system operation safety.

5. Intelligent Control and Remote Monitoring

Modern constant pressure water make-up system generally use microcomputer control technology and advanced sensor technology to achieve intelligent control and remote monitoring. Users can remotely view the system operating status, adjust setting parameters, and receive fault alarm information through mobile APPs, computers and other terminal devices. This intelligent control method not only improves the convenience and flexibility of the system, but also enables users to discover and deal with potential problems in time, ensuring that the system is always in optimal operating condition.

6. Wide Applicability

The constant pressure water supply system has wide applicability and can be used in various industrial production and building water supply and drainage systems. Whether it is cooling water systems, steam systems in industrial production, or fire protection systems, air conditioning systems, etc. in building water supply and drainage systems, constant pressure water make-up system can play an important role. Its diverse configurations and flexible installation methods allow the constant pressure water supply device to adapt to the needs of different scenarios and provide users with more comprehensive and reliable solutions.

To sum up, the constant pressure water supply system plays an indispensable role in industrial production and building water supply and drainage systems. By maintaining constant system pressure, automatic water replenishment and leak detection, energy saving and efficiency improvement, exhaust and degassing, intelligent control and remote monitoring, the constant pressure water make-up system ensures the normal and efficient operation of the system, bringing users significant economic and social benefits.
