TG Series Liquid-Liquid Plate Heat Exchanger for Air Conditioning System

Plate Heat Exchangers

A plate heat exchanger is a type of heat exchanger that uses a series of thin metal plates to transfer heat between two fluids. The plates are typically corrugated to increase their surface area and create turbulence, which improves heat transfer efficiency. The two fluids flow through the heat exchanger in separate channels, with the hot fluid transferring its heat to the cooler fluid as they pass by each other on opposite sides of the plates. Plate heat exchangers are commonly used in applications such as heating and cooling systems, refrigeration, and industrial processes where efficient heat transfer is required. They are known for their compact size, low maintenance requirements, and high heat transfer efficiency.

Advanced Quality

Customized Designs

Nanjing Beite has a rich combination of plate heat exchanger models and specifications to meet the needs of HVAC, refrigeration and industry, and provides more economical and stable performance heat exchange solutions according to working conditions.

Excellent Design and Performance

－Detachable Structure

Advantanges of Plate Heat Exchangers

Copact Structure: Plate heat exchangers have a smaller footprint than other types of heat exchangers, making them ideal for applications where space is limited.

High Heat Transfer Efficiency: It has a compact structure, can perform heat exchange at a temperature difference of 0.5~1℃, the design pressure is as high as 30Bar. And the maximum processing capacity can reach 4500m3/h. the improved plate diversion design effectively prevents plate fouling and improves the heat transfer coefficient which can reach up to 8000w/㎡.k.

Flexibility: Rich plate types, various angles, various groove depths, and different combinations form an ideal heat exchanger that is more suitable for working conditions. The plate positioning system and single-side flow design as well as special clamping size markings facilitate installation, operation and maintenance. Heat exchangers are available in different materials, such as plates made of stainless steel, titanium or other special alloys, to meet different industrial needs. Thermal mixing mode can achieve countless combinations by changing the flow mode or increasing the number of flow channels. From a single counter-flow mode of two fluids to a multi-process flow mode of three or more fluids, all can be realized, providing designers with more and more reasonable choices to meet different process requirements.

Cost-effective: The plates are formed in one go, using high-precision molds to reduce the physical stress of the plates and improve the balance of the plates, greatly extending the service life of the plates; The plates are easy to inspect and clean, and can be cleaned by countercurrent flushing in many situations. Routine cleaning does not take much time and does not require specially trained personnel; All series are adhesive-free style, reducing operation and maintenance costs and facilitating repairs. Heat transfer and pressure can be adjusted. By adjusting the heat transfer coefficient and pressure drop through the combination of plates, a good heat transfer coefficient can be obtained, thereby reducing equipment investment. Due to its high heat transfer coefficient, easy installation and maintenance, the initial investment and operation and maintenance costs are greatly reduced.

Applications of Plate Heat Exchangers

Plate heat exchangers are widely used in various industrial fields, especially suitable for the following occasions:

1. Heat exchange in air conditioning system;

2. Heat exchange in chemical production process;

3. Heat exchange in gas boilers;

4. Heat exchange in mining processing;

5. Heat exchange in ship engine cooling system;

6. Heat exchange in food processing;

7. Heat exchange in the petrochemical industry, etc.
