Air Dirt Separator: Efficient Air and Dirt Removal for Hydronic Systems

An Air Dirt Separator is a mechanical device designed to help prevent air bubbles and solid dirt particles from circulating within hydronic and HVAC systems. An ADS is important to help increase efficiency, prevent damage to equipment, and allow HVAC systems to run trouble-free for years to come.

Air build-up and contaminants in heating, cooling, and industrial water systems cause inefficient operations. By installing an air dirt separator, you can rid your HVAC or water treatment system of this problem.

What Is an Air Dirt Separator?

An air dirt separator is an integrated filter designed to filter out:

Tiny air bubbles found in system water

Released dissolved air during operation

Rust, sand, sludge and other dirt particles

It is always on as the system operates providing clean circulating water that is free of air.

How Does an Air Dirt Separator Work?

The theory of operation involves flow reduction and separation:

Water flows into the separator chamber.

Velocity of flow is slowed down within the device.

Air rises to the top and vents automatically.

Sediment drops down into the bottom sediment chamber.

Clean water flows out to recirculate.

Some separators employ coalescing media or magnetic separation.

Key Benefits of Air Dirt Separator

1) Better System Performance

Eliminating air and dirt helps to achieve maximum heat transfer capability and stable hydraulic performance

2) Protection of Equipment:

Avoid damage to sensitive equipment like

Pumps

Heat exchangers

Valves

Boilers

Chillers

3) Low Maintenance Cost

Cleaner system water means less fouling, corrosion and blockages. Maintenance costs are greatly reduced

4) Energy Saving Performance

Air-free circulating water improves flow efficiency and minimizes pump and HVAC energy consumption.

5) Continuous Automatic Operation

The separator continues to operate automatically without stopping or manual cleaning while the system is running.

Applications of Air Dirt Separator

HVAC Heating/Cooling Systems

Commonly found in commercial buildings, hospitals, hotels and industrial HVAC applications.

District Heating Systems

Provides reliable operation in centralized heating systems.

Industrial Process Water Systems

Facilities such as factories that need clean circulating water for cooling and process control.

Boiler and Chiller Systems

Keeps sensitive heat transfer equipment safe from contamination and air-related problems.

Conclusion

An Air Dirt Separator continuously removes air and solids from hydronic systems. Cleaner systems operate more efficiently and quietly with better heat transfer and longer life. Air separators protect your equipment, save maintenance dollars and improve system performance.

Air Dirt Separator keeps your hydronic systems clean, efficient and trouble-free.
